(WL-16)
4 (2 reviews)
Technical Overview
Longer Backup Solution 16 KWh.
(WL-16)
PKR 560,000.00
In Stock
Quantity
Max: 50
Longer Backup Solution 16 KWh.
(WL-16)
Experience the future of energy storage with the Voltrix WL 16 Lithium Iron Phosphate
Battery. Designed for high-power applications, this cutting edge battery delivers a
substantial 16 kWh capacity to meet your energy needs. Built with safety and durability in
mind, the WL16 is the ideal solution for residential, commercial, or off-grid power systems.
When fully charged, the WL-16 model can run two one ton air conditioners throughout the
night, ensuring uninterrupted comfort and reliability.
Product Specifications
| Parameter | Specification |
|---|---|
| Model | WL-16 |
| Nominal Energy | 16.08 KWh |
| Cell Chemistry | 16 cells in series (16S1P) |
| Nominal Voltage | 51.2 Vdc |
| Nominal Capacity | 314 Ah |
| DoD% (Up to) | 95% |
| Voltage Range | 44.8V – 57.6V |
| Charge / Discharge current | 200 A |
| Operational Temperature | 0 ~ 55 °C |
| Voltrix BMS Protection | Over Charge/Over Discharge/Over Tempreture/Over Current/Short Circuit |
| Continuous Power | ≈ 8.0 kW @ 0.5C, 10.2 kW @ 157 A |
| Cycle Life | ≥ 6000 cycles @ 80% DoD |
| Communition Port | CAN / RS485 / RS232 |
| Dimensions (H×W×D) mm | 915 × 445 × 280 |
| Weight | ≈ 110 kg |
| Protection | IP20 |
| Remote monitoring | Bluetooth |
| Certifications & Safety | UL 1973, IEC 62619, UN38.3 transport — VERIFIED |
| Warranty | 10 Years |
-
